Description
Specifications: KV..............................................................................................................2300 Configu ration....................................................................................12N14P Stator Diameter....................................................................................22mm Stator Length..........................................................................................4mm Shaft Diameter.......................................................................................2mm Motor Dimensions(Dia.*Len)...............................................Φ27×16.5mm Weight (g)...................................................................................................23g ldle current(10)@10v(A)..........................................................................0.3A No.of Cells(Lipo).....................................................................................2-3S Max Continuous current(A)180S...............................................................8A Max Continuous Power(W)180S...........................................................88W Max. efficiency current.................................................................(2.2-6A)80% internal resistance..............................................................................290mΩ
