SunnySky X Series V3 X3126 V3 Brushless Motors

[TABS]OVERVIEW

KV550

Stator Diameter	31mm	Rotor Diameter	37.7mm
Stator Thickness	26mm	Body Length	48mm
No.of Stator Slots	12	Max Lipo Cell	6S
No.of Rotor Poles	14	ESC	60-80A
Motor Kv	520	Recommended Prop(inch)	APC12*8/APC12*6/APC13*6.5
No-load current	1.1A/10V	Weight for aerobatics airplane	2000g (6S APC12*6\APC12*8\APC13*6.5)
Motor Resistance	28.2mΩ	Weight for 3D airplane	1400g-1750g (6S APC12*6\APC12*8\APC13*6.5)
Max Continuous Current	65A/30s
Max Continuous Power	1600W
Weight	197g

Prop(inch)	Voltage(V)	Amps(A)	Thrust(gf)	Watts(W)	Efficiency(g/W)	RPM	Load temperature in 100% throttle
APC13*6.5	22.2	2.6	500	57.72	8.66	3976	128℃ 2min
		4.4	750	97.68	7.68	4835
		6.4	1000	142.08	7.04	5560
		8.7	1250	193.14	6.47	6125
		11.2	1500	248.64	6.03	6660
		13.8	1750	306.36	5.71	7181
		16.9	2000	375.18	5.33	7662
		20.1	2250	446.22	5.04	8120
		23.5	2500	521.7	4.79	8496
		27.4	2750	608.28	4.52	8876
		32.1	3000	712.62	4.21	9276
		41.1	3500	912.42	3.84	9790
		55.6	4160	1234.32	3.37	10700
	25	2.4	500	53.28	9.38	3962
		4	750	88.8	8.45	4790
		5.9	1000	130.98	7.63	5600
		7.9	1250	175.38	7.13	6126
		10.1	1500	224.22	6.69	6670
		12.7	1750	281.94	6.21	7191
		15.2	2000	337.44	5.93	7687
		18.2	2250	404.04	5.57	8150
		21.6	2500	479.52	5.21	8500
		25	2750	555	4.95	8900
		29.2	3000	648.24	4.63	9276
		37	3500	821.4	4.26	9800
		47.4	4000	1052.28	3.80	10450
		65.2	4600	1447.44	3.18	11000
APC12*6	22.2	2.7	500	59.94	8.34	4570	110℃ 5min
		4.5	750	99.9	7.51	5661
		6.6	1000	146.52	6.83	6432
		8.9	1250	197.58	6.33	7021
		11.5	1500	255.3	5.88	7807
		14.1	1750	313.02	5.59	8366
		17.2	2000	381.84	5.24	8810
		21.6	2250	479.52	4.69	9156
		24.6	2500	546.12	4.58	9922
		42.3	3428	939.06	3.65	11201
	25	2.4	500	60	8.33	4589
		4	750	100	7.50	5648
		5.8	1000	145	6.90	6414
		8	1250	200	6.25	7052
		10.2	1500	255	5.88	7796
		12.6	1750	315	5.56	8320
		15.8	2000	395	5.06	8848
		19.3	2250	482.5	4.66	9176
		22.6	2500	565	4.42	9900
		27.1	2750	677.5	4.06	10170
		31.2	3000	780	3.85	10602
		39.9	3500	997.5	3.51	11436
		52.3	4106	1307.5	3.14	12203
APC12*8	22.2	2.6	500	57.72	8.66	4317	119℃ 3min
		4.6	750	102.12	7.34	5229
		7	1000	155.4	6.44	5910
		9.3	1250	206.46	6.05	6653
		12.4	1500	275.28	5.45	7052
		16	1750	355.2	4.93	7844
		18.6	2000	412.92	4.84	8262
		23.8	2250	528.36	4.26	8674
		30.4	2500	674.88	3.70	7247
		35.1	2750	779.22	3.53	9752
		50.1	3284	1112.22	2.95	10787
	25	2.4	500	60	8.33	4308
		4.1	750	91.02	8.24	5200
		6.1	1000	135.42	7.38	5890
		8.5	1250	188.7	6.62	6612
		10.9	1500	241.98	6.20	7078
		14.1	1750	313.02	5.59	7801
		17.3	2000	384.06	5.21	8239
		22.3	2250	495.06	4.54	8645
		28.2	2500	626.04	3.99	9278
		31.9	2750	708.18	3.88	9702
		38.2	3000	848.04	3.54	10427
		61.6	3934	1367.52	2.88	11756



KV800

Stator Diameter	31mm	Rotor Diameter	37.7mm
Stator Thickness	26mm	Body Length	48mm
No.of Stator Slots	12	Max Lipo Cell	3-4S
No.of Rotor Poles	14	ESC	60-80A
Motor Kv	800	Recommended Prop(inch)	APC12*8/APC12*6/APC13*6.5
No-load current	1.9A/10V	Weight for aerobatics airplane	1800g (4S APC12*6\APC12*8\APC13*6.5)
Motor Resistance	16.8mΩ	Weight for 3D airplane	1400g-1600g (3s 14*8) (4S APC12*6\APC12*8\APC13*6.5)
Max Continuous Current	75A/30s
Max Continuous Power	1260W
Weight	196g

Prop(inch)	Voltage(V)	Amps(A)	Thrust(gf)	Watts(W)	Efficiency(g/W)	RPM	Load temperature in 100% throttle
APC13*6.5	14.8	3.9	500	57.72	8.66	3992	99℃ 10min
		6.6	750	97.68	7.68	4860
		9.6	1000	142.08	7.04	5556
		12.9	1250	190.92	6.55	6213
		17	1500	251.6	5.96	6760
		21.3	1750	315.24	5.55	7156
		25.9	2000	383.32	5.22	7742
		30.6	2250	452.88	4.97	8160
		36.1	2500	534.28	4.68	8500
		42.9	2750	634.92	4.33	8922
		54.8	3000	811.04	3.70	9467
	16.8	3.5	500	58.8	8.50	3988
		5.8	750	97.44	7.70	4829
		8.6	1000	144.48	6.92	5527
		11.6	1250	194.88	6.41	6235
		14.9	1500	250.32	5.99	6770
		19	1750	319.2	5.48	7148
		23	2000	386.4	5.18	7766
		27.4	2250	460.32	4.89	8152
		32.1	2500	539.28	4.64	8543
		37.8	2750	635.04	4.33	8832
		47.4	3000	796.32	3.77	9270
		69.3	3700	1164.24	3.18	10345
APC12*6	14.8	4.2	500	62.16	8.04	4631	87℃ 10min
		6.8	750	100.64	7.45	5629
		10.2	1000	150.96	6.62	6456
		13.6	1250	201.28	6.21	7166
		17.6	1500	260.48	5.76	7655
		22.4	1750	331.52	5.28	8231
		27.2	2000	402.56	4.97	8777
		36.7	2250	543.16	4.14	9162
		45.6	2650	674.88	3.93	10008
	16.8	3.7	500	62.16	8.04	4668
		6.1	750	102.48	7.32	5607
		9.1	1000	152.88	6.54	6440
		12.6	1250	211.68	5.91	7180
		15.8	1500	265.44	5.65	7714
		20.4	1750	342.72	5.11	8214
		24.1	2000	404.88	4.94	8890
		29.6	2250	497.28	4.52	9298
		35.1	2500	589.68	4.24	9790
		41.8	2750	702.24	3.92	10143
		56.4	3260	947.52	3.44	11005
APC12*8	14.8	4.3	500	63.64	7.86	4210	93℃ 10min
		7.2	750	106.56	7.04	5092
		10.3	1000	152.44	6.56	5856
		14.9	1250	220.52	5.67	6532
		19.2	1500	284.16	5.28	7053
		24.5	1750	362.6	4.83	7605
		30.1	2000	445.48	4.49	8220
		38.1	2250	563.88	3.99	8659
		46.1	2500	682.28	3.66	9135
		53.5	2600	791.8	3.28	9576
	16.8	3.7	500	62.16	8.04	4223
		6.6	750	110.88	6.76	5112
		9.8	1000	164.64	6.07	5833
		13.1	1250	220.08	5.68	6549
		17.3	1500	290.64	5.16	7027
		21.2	1750	356.16	4.91	7670
		27.1	2000	455.28	4.39	8266
		33.2	2250	557.76	4.03	8675
		38.3	2500	643.44	3.89	9164
		47.4	2750	796.32	3.45	9725
		66.1	3200	1110.48	2.88	10446
