Description
Product Specifications:
- Operating voltage: 3.8 - 8.4 volts (HV)
- Case thickness: 8 mm
- Housing width: 23.5 mm
- Housing height: 16.6 mm
- Weight: 8 g
- Housing material: CNC-milled aluminum
- Servo motor: Coreless bell anchor
- Position sensor: Potentiometer
- Positioning force:
- 14 Ncm at 3.8 volts
- 22 Ncm at 6.0 volts
- 28 Ncm at 8.4 volts
- Adjustment time:
- 0.18 sec / 60° at 3.8 volts
- 0.15 sec / 60° at 6.0 volts
- 0.09 sec / 60° at 8.4 volts
- Fastening straps: Included
- Servo gear: Phosphor bronze + steel
- Camp: Ball-bearing
- Connection cable plug system: Approx. 15 cm Graupner connector
Package Contents:
- 1 Servo
- 3 Plastic servo arms
- 1 Servo arm screw
- 4 Fastening screws
